Natural SBR insulated marine control cable

Natural SBR insulated marine control cable application

The cable is mainly suitable for all kinds of ships and offshore oil platforms andbuildings control system.

Natural SBR insulatedmarine control cable standards&certificates

IEC 60092-350

IEC 60092-376

IEC 60332-1-2

IEC 60332-3-22

IEC 60754-1/2

IEC 61034

CCS、ABS、DNV、BV、GL、LR、NK、KR、RINA、RS

Natural SBR insulated marine control cable Service condition

1.Rated Voltage:U0/U(Um):150/250(300)V

2.Long term allowable working temperature:70℃

3.When short circuit,duration less than 5s,conductor max. temperature no more than 150℃

4.Laying temperature no less than 0℃,bending radius for single core should be no less than 10D,multi core cable should be no less than 6D,D stands for cable diameter.

Natural SBR insulated marine control cable Model

Model	Combustion	Name
CKXF	DA/SA/NA	Natural SBR insulated CR sheathed marine control cable
CKXF80	DA/SA/NA	Natural SBR insulated CR inner sheathed bare copper wire braid armored marine control cable
CKEF82	DA/SA/NA	Natural SBR insulated CR inner sheathed bare copper wire braid armored PVC outer sheathed marine control cable
CKXF90	DA/SA/NA	Natural SBR insulated CR inner sheathed steel wire braid armored marine control cable
CKXF92	DA/SA/NA	Natural SBR insulated CR inner sheathed steel wire braid armored PVC outer sheathed marine control cable
CKXV	DA/SA/NA	Natural SBR insulated PVC sheathed marine control cable
CKXV80	DA/SA/NA	Natural SBR insulated PVC inner sheathed bare copper wire braid armored marine control cable
CKXV82	DA/SA/NA	Natural SBR insulated PVC inner sheathed bare copper wire braid armored PVC outer sheathed marine control cable
CKXV90	DA/SA/NA	Natural SBR insulated PVC inner sheathed steel wire braid armored marine control cable
CKXV92	DA/SA/NA	Natural SBR insulated PVC inner sheathed steel wire braid armored PVC outer sheathed marine control cable
Note:The cable model that is not in the list can be produced as customer requested.
