Offshore cable

Offshore cable application

Product is suitable for land, sea oil drilling platform with a high-power transmission and electrical control devices, cable has good heat resistance, high current-carrying capacity, flexibility, resistance to flexing, oil resistance, abrasion resistance, low temperature resistance, corrosion resistance, aging resistance, sunlight , moisture-resistant, flame retardant, halogen and low toxicity.

Offshore Cable Standards

IEC 60092,IEEE 45,1580,UL 1309,NEK 606

Offshore Cable Certification

ABS,DNV,CCS,GL,LR,BV,NK,RINA

Offshore Cable Service Condition

Cable conductor allowable working temperature: -55 ~ 125 ℃
Minimum bending radius of the cable laying is not less than 6 times the cable diameter
Passed CCS certification

Offshore Cable choosing

For choosing Offshore platform cable,comprehensive things to be considered,like cable laying environment , electrical equipment systems and working conditions,Rated voltage and working ampacity correction factor , design margin and Line allowable voltage drop and so on. Selected cable not only need to meet international Electrotechnical Commission (IEC) standards, technical specifications requirements Other standards ( such as NEK606 and IEEE1580,UL1309) , etc., with Required to meet the relevant requirements of classification societies.

Offshore Cable Model and specification

Model	Specification		Model	Specification
Single Core	8AWG	646 MCM	Multi Core	2*16AWG	10*12AWG
	6 AWG	777 MCM		3*16 AWG	20*12AWG
	5 AWG	1111 MCM		8*16 AWG	37*12AWG
	4 AWG	10mm2		10*16AWG	2*10AWG
	3 AWG	16mm2		37*16AWG	3*10AWG
	2 AWG	25mm2		60*16AWG	4*10AWG
	1 AWG	35mm2		2*14AWG	5*10AWG
	1/0 AWG	50mm2		3*14AWG
	2/0 AWG	70mm2		4*14AWG
	3/0 AWG	95mm2		5*14AWG
	4/0 AWG	120mm2		6*14AWG
	263 MCM	150mm2		10*14AWG
	313 MCM	185mm2		37*14AWG
	374 MCM	240mm2		2*12AWG
	444 MCM	300mm2		3*12AWG
	535 MCM			4*12AWG
