Double Gun Working Stud Welding Machine
Double Gun Working Stud Welding Machine:
1. Application:
It is generally used in various aspects as the automotive, boiler, construction steel structure and ship building.
2. Specification:
RSN7-2500-2 Double Gun Working Stud Welding Machine:
|
Model |
RSN7-2500-2 |
|
|
Working Condition |
Single Gun Working |
Double Gun Working |
|
Welding Range (Diameter) |
Ф6 mm-ф28 mm |
Ф4 mm-ф18 mm |
|
Welding Current |
400A-2500A |
300A-1250A |
|
Welding Speed |
Ф28 mm 8 pcs/min |
Ф18 mm 8 pcs/min |
|
Welding Time |
0.1S-3.0S |
|
|
Input Power |
AC 3-300V-440V, 50/60 HZ |
|
|
Rated Input Capacity |
90 KW |
|
|
Power Switch |
160A |
|
|
Protection Grade |
IP23 |
|
|
Cooling Way |
F |
|
|
Dimension |
960x418x760 mm |
|
|
Weight |
168 kg |
|
|
Cable Specification |
3x16 mm2 |
|
RSN7-3150-2 Double Gun Working Stud Welding Machine:
|
Model |
RSN7-3150-2 |
|
|
Working Condition |
Single Gun Working |
Double Gun Working |
|
Welding Range (Diameter) |
Ф6 mm-ф36 mm |
Ф4 mm-ф20 mm |
|
Welding Current |
400A-3150A |
300A-1550A |
|
Welding Speed |
Ф36 mm 8 pcs/min |
Ф20 mm 8 pcs/min |
|
Welding Time |
0.1S-3.0S |
|
|
Input Power |
AC 3-300V-440V, 50/60 HZ |
|
|
Rated Input Capacity |
120 KW |
|
|
Power Switch |
225A |
|
|
Protection Grade |
IP23 |
|
|
Cooling Way |
F |
|
|
Dimension |
990x418x760 mm |
|
|
Weight |
180 kg |
|
|
Cable Specification |
3x25 mm2 |
|
RSN7-4000-2 Double Gun Working Stud Welding Machine:
|
Model |
RSN7-4000-2 |
|
|
Working Condition |
Single Gun Working |
Double Gun Working |
|
Welding Range (Diameter) |
Ф6 mm-ф46 mm |
Ф4 mm-ф24 mm |
|
Welding Current |
400A-4000A |
400A-2000A |
|
Welding Speed |
Ф46 mm 8 pcs/min |
Ф24 mm 8 pcs/min |
|
Welding Time |
0.1S-3.0S |
|
|
Input Power |
AC 3-300V-440V, 50/60 HZ |
|
|
Rated Input Capacity |
150 KW |
|
|
Power Switch |
250A |
|
|
Protection Grade |
IP23 |
|
|
Cooling Way |
F |
|
|
Dimension |
990x418x800 mm |
|
|
Weight |
188 kg |
|
|
Cable Specification |
3x35 mm2 |
|
RSN7-5000-2 Double Gun Working Stud Welding Machine:
|
Model |
RSN7-5000-2 |
|
|
Working Condition |
Single Gun Working |
Double Gun Working |
|
Welding Range (Diameter) |
Ф8 mm-ф50 mm |
Ф6 mm-ф28 mm |
|
Welding Current |
600A-5000A |
400A-2500A |
|
Welding Speed |
Ф50 mm 8 pcs/min |
Ф28 mm 8 pcs/min |
|
Welding Time |
0.1S-3.0S |
|
|
Input Power |
AC 3-300V-440V, 50/60 HZ |
|
|
Rated Input Capacity |
190 KW |
|
|
Power Switch |
250A |
|
|
Protection Grade |
IP23 |
|
|
Cooling Way |
F |
|
|
Dimension |
990x418x800 mm |
|
|
Weight |
198 kg |
|
|
Cable Specification |
3x35 mm2
|
|
