Shear stud welding machine 3150A

Shear stud welding machine 3150A

Shear stud welding machine 3150A:

Model RSN7-3150
Welding Diameter Φ6-φ36 mm
Current adjust range 600-3150A
Welding times 0.1-3.0s
Productivity φ36mm, 8pcs/min
Power supply 280V-440V, 50/60Hz
Fuse capacitance 225A
Rated input capacity 110 kw
Protection class IP23
Cooling type F
Dimenssion(L,W,H) 880*460*980mm
Weight 160kg

Feature:
1.Smooth voltage range: 280-440V, when the work environment environment is not good enough, the unstable of voltage will not effect the welding at all.You know many machines have protection system, when the voltage is beyond the rated range, work will stop, since our range is larger than the common one(380v+-15v), you don't have to stop and start, stop and start again.
2.Quick welding speed: 10pcs per minute
3.Reliable performance: waterproof and anticorrosion circuit boards, Infineon IGBT Technologies of Germany, strictly manufactured as per CE standard,2 years warranty.
4.Digital screen panel, you can see and adjust the work current and voltage on the screen, all you need to do is just welding.

5.Light and easy moved, can be used in different environment.
