DIN 89158 MGCG Screen power cable

DIN 89158 MGCG Screen power cable application

This cable is intended for fixed installations on ships and offshore-units in all locations and open decks.The good screening qualities of the copper braid also reduce radio interferences and electrical influences to electronic installation.The cables meet the flame test requirement for bunched cables according to IEC 60332-3 and IEEE45-18.13, and perform to the SOLAS requirement.

DIN 89158 MGCG Screen power cable standards

International IEC 60092-351;
IEC 60092-353; IEC 60092-359;
IEC 60332-3-22
National DIN 89158/98;
DIN 89158/98

DIN 89158 MGCG Screen power cable construction

Conductor material	Bare copper
Conductor exibility	Stranded class 2
Insulation	HEPR
Protection	Filler or tape
Armour type	Bare copper braid
Outer sheath	Cross-linked polychloroprene rubber
Sheath colour	Black

DIN 89158 MGCG Screen power cable Characteristics

Minimum installation temperature	-10 °C
Minimum operating temperature	-35 °C
Short-circuit max. conductor temperature	250 °C
Max. conductor temperature in service	85 °C
Rated Voltage Uo/U (Um)	0.6/1 kV
Test voltage	3500 V
Flame retardant	IEC 60332-3 Cat. A
Smoke density	IEC 61034
Electro magnetic interference resistance	Yes
Gases corrosivity	IEC 60754-2
Gases toxicity	No toxicity to IEC 60754-1
Standard	DIN VDE and IEC
