U Shaped Hot Rolled Steel Sheet Pile

U Shaped Hot Rolled Steel Sheet Pile:

Quick Details

Grade:	S235, S355GP, S430GP,Q345B,MDB350	Dimensions:	6mm-17mm	Standard:	AISI,ASTM,BS,DIN,GB,JIS
Place of Origin:	Chongqing China (Mainland)	Brand Name:	HISEA	Model Number:	U, Z, HZ, OZ, L/S sheet pile
Technique:	Hot Rolled

Packaging & Delivery

Packaging Detail:	Standard Package, accordng to client's requirments.
Delivery Detail:	Within 7 to 30 days after placed order

Specifications

1. U Shaped Hot Rolled Steel Sheet Pile
2.Technology:hot rolled

3.Materials:Q235,Q345,
4.Standard:DIN,GB,JIS,ASTM

Hisea could offer kinds of steel sheet piles, including U type series, Z type series, L/S type series, Corner Piles, Box pile, and any other combined sheet piles. Any requirement pls kindly contact us.

Specification:

SIZE (Width×Height)	Active widthW₁ mm	Active heightH₁ mm	Plate thickness mm	Per piece				Face per meter of Pile wall width
SIZE (Width×Height)	Active widthW₁ mm	Active heightH₁ mm	Plate thickness mm	Section area cm²	Theoretical weight kg/m	Inertia moment Ix cm⁴	Section modulus Wx cm³	Section area cm²	Theoretical weight kg/m²	Inertia moment Ix cm⁴	Section modulus Wx cm³
SPU2	400	100	10.5	61.18	48	1240	152	153	120.1	8740	874
SPU3	400	125	13.0	76.42	60.0	2220	223	191.0	149.9	16800	1340
SPU3A	400	150	13.1	74.40	58.4	2790	250	186.0	146.0	22800	1520

SPU3B	400	160	16.0	96.9	76.1	4110	334	242.0	190.0	34400	2150
SPU4	400	170	15.5	96.99	76.1	4670	362	242.5	190.4	38600	2270
SPU5L	500	200	24.3	133.8	105	7960	520	267.6	210	63000	3150
SPU6L	500	225	27.6	153.0	120	11400	680	306.0	240	86000	3820
SPU2W	600	130	10.3	78.70	61.8	2110	203	131.2	103.0	13000	1000
SPU3W	600	180	13.4	103.9	81.6	5220	376	173.2	136.0	32400	1800
SPU4W	600	210	18.0	135.3	106	8630	539	225.5	177.0	56700	2700

Optional Steel Grades:

Model	Mechanical Feature
Model	Yield(Mpa)	Tensile(Mpa)	Elongation(%)	Impact Energy
Q235B	235	375-460	38	27
Q345B	≥345	470-630	≥21	≥34
Q345C	≥345	470-630	≥21	≥34
MDB350	≥350	470-630	≥21	≥60
MDB380	≥380	480-640	≥21	≥60
Foreign Model
S355J0	≥355	470-630	≥22	≥27
St52-3	≥355	490-630	≥22	≥27
SM490A	≥325	490-610	≥20
SM490B	≥325	490-610	≥20	≥27
SS490	≥285	490-610	≥19
