Termite resistant and rodent-resistant Power Cable

Termite-resistant and rodent-resistant Power Cable

Termite-resistant and rodent-resistant Power Cable Application

This product is suitable for where the ant and mouse done serious harm,and where has green environmental protection requirements,especially suitable for laying underground pipelines and electricity transmission and distribution system lines.

Termite-resistant and rodent-resistant Power Cable Features

1.the product can effectively prevent termites , rodents from damage the cable,reliable performance for a long time,no other helper methods needed;
2.the cable contains no material that contaminated the air, soil and physical, is a green environmentally friendly products ;
3. five core power cable for three-phase five-wire transmission and distribution systems , as separate from the neutral line and the ground makes the system more stable , more secure operating personnel . And the five core power cable with a unique tile-shaped design, the cable has a stable structure , light weight , small diameter characteristics.

Termite-resistant and rodent-resistant Power Cable Standards

Q/AT2003-4

Termite-resistant and rodent-resistant Power Cable Model

Model		Name
Cu Core	AL Core	Name
WFYS-YJY	WFYS-YJLY	Copper Core(Aluminum Core)XLPE insulated Termite-resistant and rodent-resistant PO sheathed power cable
WFYS-YJY23	WFYS-YJLY23	Copper Core(Aluminum Core)XLPE insulated steel tape armored Termite-resistant and rodent-resistant PO sheathed power cable
WFYS-YJY33	WFYS-YJLY33	Copper Core(Aluminum Core)XLPE insulated thin steel wire armored Termite-resistant and rodent-resistant PO sheathed power cable
WFYS-YJY43	WFYS-YJLY43	Copper Core(Aluminum Core)XLPE insulated thick steel wire armored Termite-resistant and rodent-resistant PO sheathed power cable
WFYS-YJY53	WFYS-YJLY53	Copper Core(Aluminum Core)XLPE insulated Corrugated steel tape armored Termite-resistant and rodent-resistant PO sheathed power cable

Termite-resistant and rodent-resistant Power Cable specification

Model		Cores	Nominal Cross-section mm2	Rated Voltage KV
Cu	AL	Cores	Nominal Cross-section mm2	Rated Voltage KV
WFYS-YJY	WFYS-YJLY	1	2.5--300	0.6/1
		2	2.5--185
		3	1.5--300
		3+1、4	4--300
		5、3+2、4+1	4--300
WFYS-YJY23	WFYS-YJLY23	1	10--300
WFYS-YJY33	WFYS-YJLY33	2	4--185
WFYS-YJY43	WFYS-YJLY43	3、3+1、4	4--300
WFYS-YJY53	WFYS-YJLY53	5、3+2、4+1	4--300
