JISC 3410 MV power cable

JISC 3410 MV power cable

JISC 3410 MV power cable

JISC 3410 MV power cable application

This Cable can be applied in Marine&Offshore and various ships, ship repair and oil platforms and other offshore buildings control device and general electric lighting,machinery and equipment of factories and mines are also equally applicable.

JISC 3410 MV power cable standards

JISC 3410-1999
IEC 60092-350
IEC 60092-354
IEC 60332-1
IEC 60332-3 Cat.A(for FA-type)

JISC 3410 MV power cable Model

(FA-) SPYCB

(FA-) SPYCBY

(FA-) TPYC

(FA-) TPYCY

JISC 3410 MV power cable construction


Conductor T(S) Tinned annealed stranded copper, class 2 according to IEC 60228
Conductor screen
Semi-conducting compound
Insulation P 85°C EPR as per IEC 60092-351
Insulation screen
Semi-conducting compound /Tinned copper tape
Filler
Non-hygroscopic material (If necessary)
Bedding Y PVC,ST2 type
Armor C
(CB) 		Galvanized steel wire braid(-C TYPE) or
copper alloy wire braid(-CB TYPE)
Sheath Y PVC ST2 type
Core identification
3C Red, Yellow, Blue
Outer sheath color
Red

JISC 3410 MV power cable specification

3.6/6KV (FA-) SPYC, SPYCB

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-) SPYC, SPYCB
Nominal Cross-section Strand No./Diameter Diameter O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm Kg / Km

10

7/1.35

4.05

2.5

1.3

15.8

0.3

17.4

0.9

480

16

7/1.7

5.1

2.5

1.4

17.1

0.3

18.7

0.9

680

25

7/2.14

6.42

2.5

1.4

18.4

0.3

20

1

830

35

7/2.52

7.56

2.5

1.5

19.8

0.3

21.3

1.1

970

50

19/1.78

8.9

2.5

1.5

21.1

0.3

22.7

1.1

1160

70

19/2.14

10.7

2.5

1.6

23.1

0.3

24.7

1.2

1370

95

19/2.52

12.6

2.5

1.7

25.2

0.3

26.8

1.3

1740

120

37/2.03

14.2

2.5

1.7

26.8

0.3

28.4

1.4

2010

150

37/2.25

15.8

2.5

1.8

28.6

0.3

30.2

1.5

2450

185

37/2.52

17.6

2.5

1.9

30.7

0.4

32.8

1.6

2650

240

61/2.25

20.3

2.6

2

33.7

0.4

35.8

1.8

3200

300

61/2.52

22.7

2.8

2.1

36.8

0.4

38.9

1.9

4150

3.6/6KV (FA-) SPYCY, SPYCBY

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-) SPYCY, SPYCBY
Nominal Cross-section Strand No./Diameter Diameter Sheath Thickness O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm mm Kg / Km

10

7/1.35

4.05

2.5

1.3

15.8

0.3

1.1

19.8

1

580

16

7/1.7

5.1

2.5

1.4

17.1

0.3

1.1

21

1.1

780

25

7/2.14

6.42

2.5

1.4

18.4

0.3

1.1

22.3

1.1

950

35

7/2.52

7.56

2.5

1.5

19.8

0.3

1.1

23.7

1.2

1100

50

19/1.78

8.9

2.5

1.5

21.1

0.3

1.2

25.3

1.3

1300

70

19/2.14

10.7

2.5

1.6

23.1

0.3

1.2

27.3

1.4

1560

95

19/2.52

12.6

2.5

1.7

25.2

0.3

1.3

29.6

1.5

1890

120

37/2.03

14.2

2.5

1.7

26.8

0.3

1.3

31.2

1.6

2200

150

37/2.25

15.8

2.5

1.8

28.6

0.3

1.3

33

1.6

2720

185

37/2.52

17.6

2.5

1.9

30.7

0.4

1.4

35.8

1.8

2870

240

61/2.25

20.3

2.6

2

33.7

0.4

1.5

39

2

3450

300

61/2.52

22.7

2.8

2.1

36.8

0.4

1.5

42.1

2.1

4400

3.6/6KV (FA-)TPYC

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-)TPYC
Nominal Cross-section Strand No./Diameter Diameter O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm Kg / Km

10

7/1.35

4.05

2.5

1.9

32.4

0.4

34.5

1.7

1180

16

7/1.7

5.1

2.5

2.0

34.8

0.4

36.9

1.8

1680

25

7/2.14

6.42

2.5

2.1

37.9

0.4

40.0

2.0

2130

35

7/2.52

7.56

2.5

2.2

40.6

0.4

42.7

2.1

2550

50

19/1.78

8.9

2.5

2.3

43.7

0.4

45.8

2.3

3130

70

19/2.14

10.7

2.5

2.5

47.9

0.4

50.0

2.5

3750

95

19/2.52

12.6

2.5

2.7

52.3

0.4

54.4

2.7

4880

120

37/2.03

14.21

2.5

2.8

56.1

0.4

58.2

2.9

5690

150

37/2.25

15.75

2.5

2.9

59.7

0.4

61.8

3.1

7100

185

37/2.52

17.64

2.5

3.1

64.1

0.4

66.2

3.3

8600

3.6/6KV (FA-) TPYCY

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-) TPYCY
Nominal Cross-section Strand No./Diameter Diameter Sheath Thickness O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm mm Kg / Km

10

7/1.35

4.05

2.5

1.3

15.8

0.3

1.1

19.8

1

580

16

7/1.7

5.1

2.5

1.4

17.1

0.3

1.1

21

1.1

780

25

7/2.14

6.42

2.5

1.4

18.4

0.3

1.1

22.3

1.1

950

35

7/2.52

7.56

2.5

1.5

19.8

0.3

1.1

23.7

1.2

1100

50

19/1.78

8.9

2.5

1.5

21.1

0.3

1.2

25.3

1.3

1300

70

19/2.14

10.7

2.5

1.6

23.1

0.3

1.2

27.3

1.4

1560

95

19/2.52

12.6

2.5

1.7

25.2

0.3

1.3

29.6

1.5

1890

120

37/2.03

14.2

2.5

1.7

26.8

0.3

1.3

31.2

1.6

2200

150

37/2.25

15.8

2.5

1.8

28.6

0.3

1.3

33

1.6

2720

185

37/2.52

17.6

2.5

1.9

30.7

0.4

1.4

35.8

1.8

2870

240

61/2.25

20.3

2.6

2

33.7

0.4

1.5

39

2

3450

300

61/2.52

22.7

2.8

2.1

36.8

0.4

1.5

42.1

2.1

4400

6/10KV (FA-) SPYC, SPYCB

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-) SPYC, SPYCB
Nominal Cross-section Strand No./Diameter Diameter O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm Kg / Km

16

7/1.7

5.1

3.4

1.4

19.0

0.3

20.6

1.0

660

25

7/2.14

6.42

3.4

1.5

20.6

0.3

22.1

1.1

800

35

7/2.52

7.56

3.4

1.5

21.7

0.3

23.3

1.2

990

50

19/1.78

8.9

3.4

1.6

23.2

0.3

24.8

1.2

1200

70

19/2.14

10.7

3.4

1.7

25.3

0.3

26.8

1.3

1460

95

19/2.52

12.6

3.4

1.7

27.2

0.3

28.7

1.4

1800

120

37/2.03

14.21

3.4

1.7

28.8

0.3

30.3

1.5

2100

150

37/2.25

15.75

3.4

1.9

30.7

0.4

32.8

1.6

2600

185

37/2.52

17.64

3.4

1.9

32.6

0.4

34.7

1.7

2750

240

61/2.25

20.25

3.4

2.1

35.7

0.4

37.7

1.9

3300

300

61/2.52

22.68

3.4

2.1

38.1

0.4

40.2

2.0

4300

6/10KV (FA-) SPYCY, SPYCBY

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-) SPYCY, SPYCBY
Nominal Cross-section Strand No./Diameter Diameter Sheath Thickness O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm mm Kg / Km

16

7/1.7

5.1

3.4

1.4

19.0

0.3

1.1

22.9

1.1

870

25

7/2.14

6.42

3.4

1.5

20.6

0.3

1.2

24.7

1.2

980

35

7/2.52

7.56

3.4

1.5

21.7

0.3

1.2

25.8

1.3

1110

50

19/1.78

8.9

3.4

1.6

23.2

0.3

1.2

27.4

1.4

1360

70

19/2.14

10.7

3.4

1.7

25.3

0.3

1.3

29.6

1.5

1720

95

19/2.52

12.6

3.4

1.7

27.2

0.3

1.3

31.5

1.6

2080

120

37/2.03

14.21

3.4

1.7

28.8

0.3

1.4

33.3

1.7

2290

150

37/2.25

15.75

3.4

1.9

30.7

0.4

1.4

35.8

1.8

2810

185

37/2.52

17.64

3.4

1.9

32.6

0.4

1.5

37.9

1.9

2950

240

61/2.25

20.25

3.4

2.1

35.7

0.4

1.5

41.0

2.0

3550

300

61/2.52

22.68

3.4

2.1

38.1

0.4

1.6

43.6

2.2

4550

6/10KV (FA-)TPYC

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-)TPYC
Nominal Cross-section Strand No./Diameter Diameter O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm Kg / Km

16

7/1.7

5.1

3.4

2.2

39.3

0.4

41.4

2.1

1950

25

7/2.14

6.42

3.4

2.3

42.4

0.4

44.5

2.2

2370

35

7/2.52

7.56

3.4

2.4

45.1

0.4

47.2

2.4

2950

50

19/1.78

8.9

3.4

2.5

48.2

0.4

50.3

2.5

3600

70

19/2.14

10.7

3.4

2.7

52.4

0.4

54.5

2.7

4350

95

19/2.52

12.6

3.4

2.8

56.8

0.4

58.9

2.9

5380

120

37/2.03

14.21

3.4

3.0

60.6

0.4

62.7

3.1

6200

150

37/2.25

15.75

3.4

3.1

64.2

0.4

66.3

3.3

7700

185

37/2.52

17.64

3.4

3.3

68.6

0.4

70.7

3.5

9200

6/10KV (FA-) TPYCY

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-) TPYCY
Nominal Cross-section Strand No./Diameter Diameter Sheath Thickness O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm mm Kg / Km

16

7/1.7

5.1

3.4

2.2

39.3

0.4

1.6

44.9

2.2

2590

25

7/2.14

6.42

3.4

2.3

42.4

0.4

1.7

48.2

2.4

2920

35

7/2.52

7.56

3.4

2.4

45.1

0.4

1.8

51.0

2.5

3330

50

19/1.78

8.9

3.4

2.5

48.2

0.4

1.9

54.3

2.7

4050

70

19/2.14

10.7

3.4

2.7

52.4

0.4

2.0

58.7

2.9

5130

95

19/2.52

12.6

3.4

2.8

56.8

0.4

2.1

63.4

3.2

6210

120

37/2.03

14.21

3.4

3.0

60.6

0.4

2.2

67.3

3.4

6860

150

37/2.25

15.75

3.4

3.1

64.2

0.4

2.3

71.1

3.6

8430

185

37/2.52

17.64

3.4

3.3

68.6

0.4

2.4

75.7

3.8

9990

8.7/15KV (FA-) SPYC, SPYCB

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-) SPYC, SPYCB
Nominal Cross-section Strand No./Diameter Diameter O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm Kg / Km

25

7/2.14

6.42

4.5

1.6

23.1

0.3

24.7

1.2

790

35

7/2.52

7.56

4.5

1.6

24.3

0.3

25.8

1.3

1200

50

19/1.78

8.9

4.5

1.7

25.8

0.3

27.4

1.4

1370

70

19/2.14

10.7

4.5

1.8

27.8

0.3

29.4

1.5

1620

95

19/2.52

12.6

4.5

1.8

29.7

0.3

31.3

1.6

2010

120

37/2.03

14.21

4.5

1.9

31.6

0.4

33.6

1.7

2300

150

37/2.25

15.75

4.5

2.0

33.3

0.4

35.4

1.8

2780

185

37/2.52

17.64

4.5

2.0

35.2

0.4

37.3

1.9

2850

240

61/2.25

20.25

4.5

2.1

38.0

0.4

40.1

2.0

3450

300

61/2.52

22.68

4.5

2.2

40.7

0.4

42.7

2.1

4450

8.7/15KV (FA-) SPYCY, SPYCBY

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-) SPYCY, SPYCBY
Nominal Cross-section Strand No./Diameter Diameter Sheath Thickness O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm mm Kg / Km

25

7/2.14

6.42

4.5

1.6

23.1

0.3

1.2

27.3

1.4

920

35

7/2.52

7.56

4.5

1.6

24.3

0.3

1.3

28.6

1.4

1340

50

19/1.78

8.9

4.5

1.7

25.8

0.3

1.3

30.2

1.5

1550

70

19/2.14

10.7

4.5

1.8

27.8

0.3

1.3

32.2

1.6

1870

95

19/2.52

12.6

4.5

1.8

29.7

0.3

1.4

34.3

1.7

2290

120

37/2.03

14.21

4.5

1.9

31.6

0.4

1.4

36.6

1.8

2600

150

37/2.25

15.75

4.5

2.0

33.3

0.4

1.5

38.6

1.9

3050

185

37/2.52

17.64

4.5

2.0

35.2

0.4

1.5

40.5

2.0

3060

240

61/2.25

20.25

4.5

2.1

38.0

0.4

1.6

43.5

2.2

3690

300

61/2.52

22.68

4.5

2.2

40.7

0.4

1.7

46.4

2.3

4690

8.7/15KV (FA-)TPYC

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-)TPYC
Nominal Cross-section Strand No./Diameter Diameter O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm Kg / Km

25

7/2.14

6.42

4.5

2.5

48.0

0.4

50.1

2.5

2350

35

7/2.52

7.56

4.5

2.6

50.6

0.4

52.7

2.6

3580

50

19/1.78

8.9

4.5

2.7

53.8

0.4

55.8

2.8

4110

70

19/2.14

10.7

4.5

2.9

58.0

0.4

60.0

3.0

4860

95

19/2.52

12.6

4.5

3.0

62.4

0.4

64.5

3.2

6030

120

37/2.03

14.21

4.5

3.2

66.2

0.4

68.2

3.4

6910

150

37/2.25

15.75

4.5

3.3

69.8

0.4

71.8

3.6

8340

185

37/2.52

17.64

4.5

3.5

74.2

0.4

76.2

3.8

9700

8.7/15KV (FA-) TPYCY

Conductor Insulation Thickness Thick. of Bedding Dia. over Bedding Dia. of Armor (FA-) TPYCY
Nominal Cross-section Strand No./Diameter Diameter Sheath Thickness O.D. Tolerance Reference Weight
mm² No./mm mm mm mm mm mm mm mm mm Kg / Km

25

7/2.14

6.42

4.5

2.5

48.0

0.4

1.9

54.0

2.7

2750

35

7/2.52

7.56

4.5

2.6

50.6

0.4

1.9

56.8

2.8

4030

50

19/1.78

8.9

4.5

2.7

53.8

0.4

2.0

60.1

3.0

4640

70

19/2.14

10.7

4.5

2.9

58.0

0.4

2.1

64.5

3.2

5610

95

19/2.52

12.6

4.5

3.0

62.4

0.4

2.2

69.2

3.5

6890

120

37/2.03

14.21

4.5

3.2

66.2

0.4

2.3

73.2

3.7

7820

150

37/2.25

15.75

4.5

3.3

69.8

0.4

2.4

77.0

3.8

9160

185

37/2.52

17.64

4.5

3.5

74.2

0.4

2.5

81.6

4.1

10460

JISC 3410 MV power cable Show

JISC 3410 MV Power Cable.jpg

Finished Cable

Related products for "JISC 3410 MV power cable"

CONTACT WITH US NOW

Our mail: manager@hiseamarine.com

Society certificates

Hi-Sea Group-Obtained-certification
