Engine room inclined ladder

Engine room inclined ladder:

Features:

This ladder is used to reach the engine room in the ships, which is made of steel, or alumium, with steel steps.

Optional Model:

1.Available in marine steel, stainless steel and aluminum, copper materials

2.Turnover device : upper platform, Driving tube, lazy arm, pillar

3.Fastening device : Fastening hooks, Support tube

4.Customize available. OEM service and Special requirement is available

5.With various certificates.

Specifications:

There's several types. Frame can be made of flat steel or angle, with checker plate or wire decking as steps.

Model	Ladder frame	Step	Inclination angle	B	Height
1	Flat steel	checker plate	55	450mm	750-2850mm
2	Fllat steel	wire decking	55	450mm	750-2850mm
3	Angle steel	checker plate	60	600mm	3000-4050mm
4	Angle steel	wire decking	60	600mm	3000-4050mm

We can also provide various kinds of marine ladders, including

1. Appliance for pilot ladder

2. Accommodation ladder for diver

3. Bulkwark ladder

4. Ladder for draft reading

5. Engine room inclined ladder

6. Cargo hold& oil tank ladder

7. Stainless steel vertical ladder

8. Cargo hold inclined ladder

9. Cargo hold inclined ladder

10. Marine steel inclined ladder

11. Marine steel vertical ladder

12. Aluminum pipe vertical ladder

13. Aluminum inclined ladder

14. Mountain ship rope ladder

15. Aluminum alloy wharf ladder

16. Pilot Ladder

17. Portable aluminum ladder

This ladder is made of stainless stee ,with checker plate as steps.
