TIOI/TICI low voltage power and control cable

TIOI/TICI low voltage power and control cable application

Halogen free power, control and lighting cable for ships and offshore-platforms

Due to its flexibility also suitable when the installation space is limited and/or for places which are difficult to access
Suitable for areas where protection against electromagnetic interference (EMI) signals is important

This cable is designed for power, lighting & control circuits up to 0.6/1kV.

Suitable for use in commercial marine applications

Maximum conductor temperature : 90℃

TIOI/TICI low voltage power and control cable standards

- Design guide : IEC 60092-350 & IEC 60092-353
- Insulation material : IEC 60092-351, XLPE
- Sheath material : IEC 60092-359, SHF1
- Flame retardant : IEC 60332-1 & IEC 60332-3 Category A
- Halogen content : IEC 60754-1, 0.5%
- Smoke emission : IEC 61034, 60%
- Cold bend/impact : CSA 22.2 No. 0.3 (-40°C / -35°C )

TIOI/TICI low voltage power and control cable construction

Classification	Code	Construction detail
Conductor		Stranded plain annealed copper wire as per IEC 60228, Class 2
Insulation	T	XLPE as per IEC 60092-351
Cabling		- Insulated conductors shall be cabled - Flame retardant & non-hygroscopic fillers may be used - Suitable tape(s) may be applied on the cabled core - A Filler may be applied to obtain a circular Cable
Inner sheath	I	SHF1 as per IEC 60092-359
Armor	O(C)	- Braid of plain annealed copper wire(o) or galvanized steel wire(c) - Coverage density : Min. 90%
Outer sheath	I	SHF1 as per IEC 60092-359,Outer sheath color : Black

Note:
The other color of sheath and insulation may be applicable when purchaser required.
Stranded tinned annealed copper wire as per IEC 60228, Class 2 may be applicable when purchaser required.

TIOI/TICI low voltage power and control cable service conditions

Minimum installation temperature	-20 °C
Maximum conductor temperature	+90 °C
Operating temperature	min. -40 °C, max. +80 °C
Outer sheath colour	black
Standard	IEC 60092-353
Approval	Approval by most important classification societies American Bureau of Shipping, Bureau Veritas, Det Norske Veritas, Lloyds Register and Germanischer Lloyd
Packaging	drums
