Railway signal cable

Railway signal cable

Railway signal cable application

This cable is intended for audio signal transmission and fixed laying railway signal and Automatic transmission control circuit device of Rated voltage of 500V AC or DC voltage 1000V and below.

Railway signal cable features

(1) Multi-torque star quads structure to ensure stable transmission performance

(2) longitudinally shielded with good resistance to electric and magnetic fields interfere with the performance and the performance of tidal

(3) has a strong mechanical and physical properties Reliability

(4) aluminum sheath with a strong shielding effect, effectively ensuring communication signals

(5) cold stage sheathed cables ambient temperature can reach -40 ℃

Railway signal cable model

Model

Name

Laying conditions

Specification(Core)

PTYV

PE insulated PVC sheath railway signal cable

Laid in the soil and tank tube can withstand greater mechanical force.

4 6

8 9 12 14 16 19

21 24 28 30

33 37 42 44

48 52

56 61

PTYY

PE insulated PE sheathed railway signal cable

PTYH22

PE insulated steel tape armored cold resistant PVC sheathed railway signal cable

PTY22

PE insulated steel tape armored PVC sheathed railway signal cable

PTY23

PE insulated steel tape armored PE sheathed railway signal cable

PTYA22

PE insulated comprehensive sheathed steel tape armored PVC sheathed railway signal cable

PTYA23

PE insulated comprehensive sheathed steel tape armored PE sheathed railway signal cable

PTYLH22

PE insulated Al sheathed steel tape armored cold resistant PVC sheathed railway signal cable

PTYL22

PE insulated Al sheathed steel tape armored PVC sheathed railway signal cable

PTYL23

PE insulated Al sheathed steel tape armored PE sheathed railway signal cable

Railway signal cable show

finished railway signal cable.jpg
