WEICHAI Marine Genset

WEICHAI marine genset features:

1.The output power range of WEICHAI marine genset is from 30kw-400kw.

2.All kinds of components of the sets have been install on common base frame,so they have compact structure and can be installed easily.

3.WEICHAI marine gensets have the character of high speed-regulating accuracy,better dynamic state performance and high efficiency.

4.Match with famous brand alternators:Siemens,Stamford,Marathon,SUNVIM,Leroy-somer.

5.WEICHAI marine genset and emergency marine genset can be used as main power or stand-by emergency power for all kinds of vessel.

6.Certificate:CCS,BV,ABS,GL,RS,CE,NK,KR.

Technical specifications

Model	Power (kw)	Diesel engine		Power factor	Voltage (V)	Dimensions (LWH)
Model	Power (kw)	model	Power (kw)	Power factor	Voltage (V)	Dimensions (LWH)
CCFJ24W	24	D226B-3CD	33	0.8	400/230	15716201231mm
CCFJ30W	30	TD226B-3CD	44			15716201231mm
CCFJ40W	40	TD226B-4CD	66			16186201431mm
CCFJ50W	50	TD226B-4CD	66			16186201431mm
CCFJ64W	64	TD226B-6CD	99			21287981336mm
CCFJ75W	75	TD226B-6CD	99			21287981336mm
CCFJ90W	90	TBD226B-6CD	132			21287981336mm
CCFJ100W	100	TBD226B-6CD	132			21287981336mm
CCFJ120W	120	TBD226B-6CD5	145			22687981336mm
CCFJ150W	150	WD615.68CD	187			315010601650mm
CCFJ180W	180	WD615.46CD	231			315010601650mm
CCFJ200W	200	WD618.42CD	259			325010602030mm
CCFJ250W	250	X6160Z-1	280			375811101945mm
CCFJ300W	300	R6160Z-1	330			375811101946mm
CCFJ350W	350	X6170ZC	390			359611461909mm
CCFJ400W	400	X6170ZC-21	456			359611461910mm
