Three Parts Trunnion Ball Valve
Three Parts Trunnion Ball Valve:
1. Brief Introduction.
Type: Trunnion
Model: Three Parts
The Three Parts Trunnion Ball Valve adopts forging technology and is widely using for petroleum pipeline, chemical industry etc.
2. Stanard:
Design and Manufacture Standard: API 6D
Flange Dimension Standard: ANSI B 16.47 (RF)
Temperature and Pressure Standard: ANSI B 16.34
Face to Face Standard: ANSI B16.10
Fire Safety Standard: API 607
Test and Inspection Standard: API 6D
3. Valve Material:
| Valve Ball | ASTM A350 LF2 |
| Valve Seat | ASTM A350 LF2 |
| Upper Valve Bonnet | A350 LF2 |
| Upper Valve Stem | ASTM A276 420 |
| O-ring | Fluorine Rubber |
4. Valve Temperature:
Working Temperature: -29 to 150 degree
5. Three Parts Trunnion Ball Valve Forging Factory Picture:
6. Three Parts Trunnion Ball Valve Half Finished Picture:
7. Three Parts Trunnion Ball Valve Finished Picture:
