SIR sheathed fire resistant flat cable

SIR sheathed fire resistant flat cable application

Silicone rubber ( flame retardant ) flat power cable is widely used in lifting,transportation,mechanical,electrical,steel,pharmaceutical,metallurgy,ports,mining,logistics,warehousing and other industries for variety of mobile equipment that rated voltage 0.6kv/1kv and below power supply and control,signaling,lighting,etc.

SIR sheathed fire resistant flat cable Service Condition

1.Rated voltage U0 / U: 0.6/1kv
2.the cable operating temperature range : Silicone -60 ℃ ~ +180 ℃; fluorine plastic -60 ℃ ~ +200 ℃
3.short ( longest lasting no more than 5S) of the conductor temperature does not exceed 250 ℃.
4.cable laying temperature should not be lower than -20 ℃.
5.cable laying minimum bend radius is 10 times the length of the small side .

SIR sheathed fire resistant flat cable Model

Model	Name
ZR-YGCB	SIR insulated and sheathed flame retardant flat power cable
ZR-YF46GRB	F46 insulated SIR sheathed flame retardant flat power cable

SIR sheathed fire resistant flat cable specification

Nominal Cross-section	Conductor Diameter	Insulation Thickness	Sheath Thickness	Spacing	Cable Outer Diameter	Reference Weight(kg)
4×1	1.29	0.8	1.6	1	17.76×6.09	225
6×1	1.29	0.8	1.6	1	25.54×6.09	360
8×1	1.29	0.8	1.6	1	33.32×6.09	380
4×1.5	1.56	1	1.6	1	20.44×6.76	291
6×1.5	1.56	1	1.6	1	29.56×6.76	360
8×1.5	1.56	1	1.6	1	38.68×6.76	469
4×2.5	2.05	1.4	1.6	1.5	27.1×8.05	333
6×2.5	2.05	1.4	1.6	1.5	39.8×8.05	536
8×2.5	2.05	1.4	1.6	1.5	52.5×8.05	608
4×4	2.6	1.8	1.7	1.7	33.3×9.6	457
6×4	2.6	1.8	1.7	1.7	49.1×9.6	790
4×6	3.15	2	1.9	2.0	38.4×11.5	615
6×6	3.15	2	1.9	2.0	56.7×11.5	1098
3×10	4.4	2.5	2.4	2.4	37.8×14.2	702
6×10	4.4	2.5	2.4	2.4	73.2×14.2	1428
3×25	6.81	2.8	2.7	2.8	48.23×17.81	1645
6×25	6.81	2.8	2.7	2.8	93.86×17.81	3325
4×35	7.9	3	3	3	70.6×19.9	2181
3×50	9.2	3.2	3.1	3.4	59.8×21.8	2681
4×50	9.2	3.2	3.1	3.4	78.8×21.8	3158
3×70	12.6	3.4	3.3	3.8	72.4×26	2878
3×120	15.4	3.8	3.07	4.2	84.8×30.4	5157
3×150	16.4	4	4.1	4.4	90.2×32.6	6171
