EU Type Mooring Chock (B type)

EU Type Mooring Chock (B type)

EU Type Mooring Chock (B type)

Mooring chock products mainly include: DIN type mooring chock, Panama mooring chock, closed mooring chock, mooring type mooring chock, Spain mooring chock, single point mooring chock, etc., but also according to their shape into round mooring chock, oval mooring chock, square mooring chock, etc.

With the development of the shipbuilding industry, mooring chock products also improved by the Ministry of Development, which is suitable for all types of vessels berthing mooring.

1.Type: EU Type
2.Size: 600x315mm,600x450mm
4.Surface: Blasting and Grey Epoxy Primer.
5.Packing: Steel Pallet

Surface: High corrosion-resistance , Mirror or Satin polished, Galvanized

Material: Stainless steel-AISI316 AISI304 ,alloy casting and carbon steel

Technics : Precision Cast

Shape: Oval/Circumference/circle

EU Type Mooring Chock.jpg

EU Type Deck Mouting Chock
Nominal Size(mm) Dimension (mm) SWL (KN) Weight (kg)
L L1 L2 H H1 H2 B
600x315 600 1200 1360 315 865 507 560 2000 728
600x450 600 1200 1360 450 1000 575 560 2000 840

EU Mooring Chock.JPG
